Produkt information
Flight ProTek35 kommer her med 2500KV Xing 2205-motorer til 6S LiPo. DJI Vista og Caddx Polar HD kamera færdigmonteret så her er det meste klart. Modellen er prætunet til at flyve jævnt og med T700 carbon har du også et stel som er meget stift og holdbart.
Anbefalet tilbehør
NYHED!
GRATIS FRAGT*
* Dette produkt kvalificerer til gratis forsendelse. Andre varer i samme ordre vil så også modtage gratis fragt.
Undtagelser er varer med deres egne specifikke forsendelseskriterier.
kr 599,-
699| 699,-
Uden din rabat kr 599,-
3|674|235
NYHED!
GRATIS FRAGT*
* Dette produkt kvalificerer til gratis forsendelse. Andre varer i samme ordre vil så også modtage gratis fragt.
Undtagelser er varer med deres egne specifikke forsendelseskriterier.
kr 1.399,-
0| 0,-
Uden din rabat kr 1.399,-
3|124|235
NYHED!
GRATIS FRAGT*
* Dette produkt kvalificerer til gratis forsendelse. Andre varer i samme ordre vil så også modtage gratis fragt.
Undtagelser er varer med deres egne specifikke forsendelseskriterier.
kr 399,-
0| 0,-
Uden din rabat kr 399,-
3|60|891
NYHED!
GRATIS FRAGT*
* Dette produkt kvalificerer til gratis forsendelse. Andre varer i samme ordre vil så også modtage gratis fragt.
Undtagelser er varer med deres egne specifikke forsendelseskriterier.
kr 699,-
0| 0,-
Uden din rabat kr 699,-
3|333|235
NYHED!
GRATIS FRAGT*
* Dette produkt kvalificerer til gratis forsendelse. Andre varer i samme ordre vil så også modtage gratis fragt.
Undtagelser er varer med deres egne specifikke forsendelseskriterier.
kr 399,-
0| 0,-
Uden din rabat kr 399,-
0|0|259
PS! Produktteksten er maskineoversat fra norsk.
Batteri, oplader, radio og FPV-briller skal købes separat, se anbefalet tilbehør.
GoPro og gopro mount er ikke inkluderet.
Inkluderet i pakken:Protek35 stelCaddx HD Polar1 X Albatross LHCP Antenne ipex 170mm2 X Nazgul 3535 propelsæt1 X TPU Naked Gopro bundstativ
2X iFlight batterirem4X XING 2205 motorer1X TPU beslag til Nebula Air Unit.Beast Whoop F7 AIO 55A V2Nødvendigt tilbehør:Batteri 6S + -1300mAh XT60FPV beskyttelsesbrillerRadioOplader| Specifikationer | |
| Akselafstand | 151 Mm |
| Nederste tallerken | 3,5 Mm |
| Topplade | 2 Mm |
| Vægt | 348,3G uden batteri |
Product details in english
After our very popular 3inch Cinematic EVA bumper BumbleBee and Green Hornet CineWhoop series, we were trying to increase performance and reduce weight for an even better and longer flight experience for a wide variety of use.
Our all new 3.5inch project is finally ready for all you content creators or those guys who like to wear some protection every now and then. Prop protection is what were talking about here...
ProTek is not necessarily just a Cinewhoop series but far more. Equipped with our all new 2203.5 motors for more power and less heat. We were able to increase speed and thrust by 50% compared to its 3inch predecessor which gives a lot more room for a lot more fun. Our GPS measured maximum speed was above 120km/h and a maximum thrust of 750g per motor (3kg in total) would even carry heavier cams than a Gopro but also do some loaded punch outs or light freestyle moves.
A lot of thought was put into the different assembly options. Our stock BNF will ship in the standard configuration but you can either do a pusher mod (flip the build upside down) or a lite mod (remove the protective plastic for weight optimization).
Durable plastic protectors with copper standoffs, portable compact design, easy accessable UBS port without disassembly, LED battery status, lost model buzzer and a universal GoPro TPU for a full size or naked GoPro. If you wanna go extra light, get one of our 5V balance plug GoPro power cables to get rid of the internal battery.
ProTek35 Prop Guards V2.0
No Props or frame in view!High performance True-AIO Board Beast Whoop F7 AIO 55A to save weight and spaceT700 Quality Carbon (40% more tensile strength compared to common 3K carbon)Lightweight one-piece frame design (Less flexibility, more Rigid, more Durable)Low Resonance frame construction (Less Jello, more Cinematic footage)Caddx Polar Vista Digital HD SystemButter smooth 2205 2205 2300KV (6S)Pre-tuned with smooth freestyle settings
Specs
*Board Beast Whoop F7 AIO 55A (LINK)
*Motor: XING 2203.5 3600KV (4S) (LINK) / XING 2205 2300KV (6S) (LINK)
*Wheelbase: 151mm
*Body Size: 118*94.5mmmm
*Bottom plate thickness: 3.5mm
*Top plate thickness: 2mm
*Top and bottom plate spacing: 20mm (aluminum standoff height)
*Propeller size: 3.5 inch
*FC pattern: 25.5*25.5mm / 20*20mmmm
*FPV cam spacing: 20mm
*Weight: 348.3g (without battery)
ProTek35 HD Quad BNF Included Components and Parts
1 x ProTek35 Frame
1 x Caddx Polar Vista Digital HD System Kit
1 x Albatross LHCP Antenna ipex 170mm
1 x TPU Bracket for Nebula Nano Air Unit
1 x TPU Antenna holder
2 x Nazgul 3535 propeller (Set of 4 - Color May Vary)
1 x iFlight Lipo Strap 15*150mm (Color May Vary)
1 x iFlight Lipo Strap 15*250mm (Color May Vary)
1 x GoPro TPU bottom stand black (GoPro Protector not included)
Beast F7 AIO 55A V2
MCU: BGA-STM32F745
MCU: BGA-STM32F745
Gyro: BMI270
Blackbox: 16MB Onboard Flash
BEC output: 5V 2.5A
Barometer: DPS310
Connector: Micro-USB
OSD: IFLIGHT OSD (AT745E?
FC Firmware?IFLIGHT_F745_AIO_V2
Mounting pattern: 25.5*25.5mm ?3mm
Dimensions: 32.5*32.5mm
Weight: 8.5g
ESC: 55A 2-6s
Uarts: 5
Current Sensor: Yes
Input: 2-6S LIPO
Current scale: 100
Constant: 55A / Burst: 60A
BLHeli: BLHeli-S
Telemetry: no
ESC Firmware: G-H-30 BLS
Mounting pattern: 25.5*25.5mm/?3mm
Dimensions:?32.5*32.5mm
